Engine
Engine type
Liquid-cooled, 4-stroke Single
Displacement
249cc
Bore x stroke
78 x 52.2 mm
Compression ratio
14.0:1
Valve/Induction system
DOHC, 4 valves
Fuel system
Fuel injection: 44 mm
Ignition
Digital DC-CDI
Starting
Electric
Lubrication
Forced lubrication, semi‑dry sump
Frame & Dimensions
Frame type
Perimeter, aluminium
Rake/Trail
Rake: 27 / Trail: 118mm
Wheel travel - front
305 mm
Wheel travel - rear
307 mm
Tyre - front
80/100-21 51M
Tyre - rear
110/90-19 63M
Steering angle - left / right
42 / 42
Dimensions (L x W x H)
2,190 x 820 x 1,265 mm
Wheelbase
1,485 mm
Ground Clearance
340 mm
Seat height
955mm
Fuel capacity
6.2 litres
Curb Mass
109.5 kg
Brakes & Suspension
Suspension - front
49 mm inverted telescopic fork with adjustable compression and rebound damping
Suspension - rear
New Uni Trak with adjustable dual-range (high/low-speed) compression damping, adjustable rebound damping and adjustable preload
Brakes - front
Single semi-floating 270 mm petal disc. Caliper: Dual-piston
Brakes - rear
Single 240 mm petal disc Caliper: Single-piston
