Engine
Engine type
Liquid-cooled, 2-stroke Single
Displacement
64 cm
Bore x stroke
44.5 x 41.6 mm
Compression ratio
8.4:1
Valve/Induction system
Piston reed valve
Fuel system
Carburettor: Mikuni VM24SS
Ignition
Electric CDI
Starting
Primary kick
Lubrication
Petrol mix
Frame & Dimensions
Frame type
Double-cradle, high-tensile steel
Rake/Trail
60 mm
Wheel travel - front
210 mm
Wheel travel - rear
240 mm
Tyre - front
60 / 100-14 30M
Tyre - rear
80 / 100-12 41M
Steering angle - left / right
40 / 40
Dimensions (L x W x H)
1,590 x 760 x 955 mm
Wheelbase
1,120 mm
Ground Clearance
305 mm
Seat height
760 mm
Fuel capacity
3.8 litres
Curb Mass
60 kg
Brakes & Suspension
Suspension - front
33 mm telescopic fork with 4-way rebound damping
Suspension - rear
Bottom-Link Uni-Trak with gas-charged shock, adjustable preload and stepless rebound damping
Brakes - front
Single 180 mm disc. Caliper: Single-piston
Brakes - rear
Single 180 mm disc. Caliper: Single-piston
